Accuracy

• 5 mm (1σ,@ 50 m range)

Precision

• 3 mm (1σ,@ 50 m range)

​

Laser Scanner

• Range : 1.5~250 m (vehicle-mounted) 1.5~1,450 m (airborne)

• Scanning rate : 2,000,000 pulses/sec

• Returns : Up to 16 Full waveform

​

Positioning

• GNSS : Full constellation

• IMU : 600 Hz

​

Imaging

• Resolution : 30 MP (Ladybug5+) / 72 MP (Ladybug6)

• Focal length : 2.5 mm (Ladybug5+) / 6.94 mm (Ladybug6)

​

Storage

• Memory : 512G, optional for 1T (ABN)/ 2TB external hard drive (VM)

​

Physical

• Weight (AP7 Single-head) : 7.5 kg (without laser and camera)

• Weight (AP7 Dual-head) : 8.3 kg (without laser and camera)

​​​
